Control box
54
RPB
Machine use
Right sequential opening of
the spraying sections:
-
O
perate switch (1) to the left.
-
Repeat proc
edure for each
section.
Right sequential shu
tting of the spraying se
ctions:
-
O
perate switch (1) to the left.
-
Repeat proc
edure for each
section.
1
1
55
57
