ENGLISH TECHNICAL PASSPORT
Ceramic hob & Induction hob
 Under any circumstances,make
sure the ceramic cooker hob is well ven-
tilated and the air inlet and outlet are not
blocked.
 Ensure the ceramic cooker hob is
in good work state. As shown below.
NOTE: The safety distance between
the hotplate and the cupboard above the
hotplate should be at least 650 mm.
А (mm) В (mm) С (mm) D E
650 50 mini 20 mini
Air
intake
Air exit
5 mm
Before you install the hob, make
sure that:
 The work surface is square and
level, and no structural members inter-
fere with space requirements.
 The work surface is made of
a heat-resistant material.
 If the hob is installed above an
oven, the oven has a built-in cooling fan.
 The installation will comply with
all clearance requirements and applica-
ble standards and regulations.
 A suitable isolating switch provid-
ing full disconnection from the mains
power supply is incorporated in the per-
manent wiring,mounted and positioned
to comply with the local wiring rules and
regulations.
 The isolating switch must be of
an approved type and provide a 3 mm air
gap contact separation in all poles (or in
all active [phase] conductors if the local
wiring rules allow for this variation of the
requirements).
 The isolating switch will be easily
accessible to the customer with the hob
installed.
 You consult local building authori-
ties and by-laws if in doubt regarding in-
stallation.
 You use heat-resistant and easyto-
clean nishes (such as ceramic tiles) for
the wall surfaces surrounding the hob.
