Küschall®Compact
4.PulloutthespringboltlockBandinsertthebarof
theT-armrestpadAintotheholderCtotherequired
height.
TheT-armrestpadcanoptionallybeinserted180°
turned.
5.Releasethespringboltlockandallowthebarofthe
T-armrestpadtoengagewithanaudible“click”inthe
nearesthole.
AdjustingtheHeight
1.PulloutthespringboltlockBandmovethearmrest
padAtotherequiredheight.
2.Releasethespringboltlockandallowittoengagewith
anaudible“click”inthenearesthole.
WARNING!
RiskofInjury
Evenifthearmrestsarelocking,theyarenot
designedtocarrytheweightoftheoccupied
wheelchair.
–Neverusethearmreststoliftthewheelchair.
–Donotusethearmrestsfortransportation
whencarryingthewheelchairup-ordownstairs.
3.8.4Mudguard
Inordertopreventdirtfromthewheelssprayingupwards,
aremovablemudguardcanbetted.Thepositionofthe
mudguardcanbeadjusted.Theadjustmentmustbecarried
outbyaqualiedtechnician.
WARNING!
Riskofinjury
Themudguardsarenotlockedandcanbeeasily
pulledoutupwards.
–Donotliftortransferthewheelchairusingthe
mudguards.
–Donotusethemudguardsfortransportation
whencarryingthewheelchairup-ordownstairs.
Removing
1.Pullthemudguardupwardsoutoftheholder.
2.Toadjusthoweasyordifcultitistopullthemudguard
outoftheholder,changethedegreetowhichthe
screwsDaretightened.
Installing
1.Pushthemudguardintotheholder.
Adjustingtheheight
1.SlightlyloosenthegrubscrewAontheclampingpart
B.
2.Movetheclampingpartupwardsordownwardsonthe
proleCtothedesiredheight.
22
1659285-C
