Kuschall Compact User Manual

ProductOverview
3.Re-tightenthegrubscrew.
4.Performthesettingonbothsides.
3.8.5Clothes-guard
Aclothes-guardcanbeinstalledtoprotectyourclothes.
3.9Legrests
WARNING!
Riskofinjury
–Neverusethelegrestsorfootplatestoliftthe
wheelchair.
Swivelling
1.ActivatethereleaseleverAandswivelthelegrestB
totheoutside.
Swivellingforwards
1.Swivelthelegrestforwardsuntilitengages.
Unhinging
1.ActivatethereleaseleverA.
2.Pullthelegrestupwards.
Hinging
1.Hingethelegrestonthefrontoftheframeandswivel
itforwardsuntilitengages.
Adjustingtheheight
1.Removescrew,washerandnutfromtheframeBwith
4mmAllenkeyand8mmspanner.
2.Slidethefootreststothedesiredheight.
3.Reinsertscrew,washerandnutontheframeBand
tightenthem(4Nm).
4.Performthesettingonbothsides.
Thedistancebetweenthelowestpartofthefootrest
andthegroundmustbeatleast50mm.Invacare
recommendsthatfootplateadjustmentiscarried
outbyaqualiedtechnician.
1659285-C23

Kuschall Compact Specifications

General

Foldable	Yes
Frame Material	Aluminum
Category	Wheelchair
Type	Manual
Wheel Size	24 inches
Seat Width	36 - 51 cm (14 - 20")
