Kuschall Compact User Manual

Options
4.9DualHandrimDHR
Thisquickreleasedualhandrimsystem(leftorrighthand)
allowstheusertodrivethewheelchairwithasinglearm
usingtwohandrimsonthesamewheelwith2possible
sidepositionsofthesmallhandrim.Theusercatchesboth
handrimstopropelthewheelchairforwardorbackwards;
turnsontheLHorRHsidebygrippingthelargeorthesmall
handrimonly.TheDHRsystemisalwaysdeliveredinpassive
rearwheelpositionforabetterstability.
Thehandrimscaneitherbeplacedinlinewith
eachother(internalposition)orwiththeinner,
smaller,handrimoutsidethelargerhandrim(external
position).Makesurethatthe3screwsBarelocked
intoposition.
CAUTION!
Riskofinjury
–Itsrecommendedthatthechangeofcontrol
sideandpositionofthesmallhandrimmustbe
carriedoutbyaqualiedtechnician.
WARNING!
Riskofinjury
–Alwaysremovethetelescopicrearwheelshaft
Cbeforeremovingtherearwheels.
WARNING!
Riskofinjury
Thewheelscomeoff
–Checkthattherearwheelissecurelylockedin
position!Itshouldnotbepossibletoremove
thewheelswhentheremovableaxlebuttonA
isinactivated.Testthisbytryingtopullthe
wheeloff.
CAUTION!
Riskofinjury
Minorbruises,pain
–Becarefulnottogetyourngerstrapped
betweentherearwheelspokesandthethree
bracketsoftheouterhandrim.
DisengagingandEngagingtheRearWheelShaft
Tofoldthewheelchairitisnecessarytodisengagethe
telescopicrearwheelshaftC.
1.DisengagethetelescopicshaftCbyslidingonepart
insidetheother.
2.Tofacilitatethisoperationmovethesmallhandrim
forwardstobackwards.
3.Reverseproceduretoengagethetelescopicrearwheel
shaft.
CAUTION!
Riskofaccident
–ThetelescopicrearwheelshaftCisanintegral
partofthewheelchairandtheuserwillbe
unabletopropelthewheelchairwithoutit.
1659285-C35

Kuschall Compact Specifications

General

Foldable	Yes
Frame Material	Aluminum
Category	Wheelchair
Type	Manual
Wheel Size	24 inches
Seat Width	36 - 51 cm (14 - 20")
