Tocontrol Yellow colour onRGBY Projector there are two ways. Below isdescribed which should beused.
• FB4 isbuilt into every RGBY Projector, FB4 has 6 color
outputs. Red, Green, Blue, Magenta, Yellow, Cyan. Normally
these 6 color outputs can be controlled only when FB4
is in „Beyond/QS mode” and when Beyond software
isused tooperate laser projector (Advanced Mode).
• IfFB4 isin„Beyond/QS mode” and QuickShow software
isused tooperate laser projector, only R, G and B colors
(signals) are used. (Use Colour Balance display mode).
• ILDA Input ofFB4 isusing only 3 input colors. Red, Green
and Blue. Normally when FB4 is in „ILDA Input“ mode,
itisnot possible tocontrol all 6 color outputs. (Use Colour
Balance display mode).
• DMX, Art-Net orAutoplay. For standard frames onSDcard
also only R, G and B colors can becontrolled. (Use Colour
Balance display mode)
