KVANT Atom Series - Connection Diagram

12  44
EN
2.6
 
Please check that all the signal and power leads are
correctly installed and that the safety keys are inserted
inall necessary positions.
!
USA ONLY: Remote Interlock Bypass
must be inserted in the E-STOP
Remote aswell inorder todisable the
interlock.
i
Both E-STOP Remote safety key and
laser system safety key must beinserted
and switched toONposition inorder
todisable the interlock.
