KVANT Atom 20 – full colour, semiconductor diode laser
system
Total Optical Power (installed): 20W
Total Optical Power (guaranteed): 20W*
*Due to Advanced Optical Correction technology used
in our laser systems the optical power output of each
laser colour within the system may slightly dier from the
specification ofrespective laser module(s) installed. This
does not aect the guaranteed total power output.
NOHD (Nominal Ocular Hazard Distance for guaranteed
power output): 1590 m
Beam diameter atlaser aperture: 6x7 mm
Beam divergence: 1mrad (full angle)
Red: 0.5/0.6 mrad
Green: 0.5/0.5mrad
Blue: 0.6/0.6 mrad
Modulation: 100 kHz | analog – 100 kHz
Module cooling: TEC
Scanning System:
Juno 5 | 35 Kpps @ 8°, 60°
Control signal: Ethernet, DMX/ArtNet, ILDA, SDcard (via
inbuilt FB4 control interface)
Power requirements: 100-240V/50-60Hz (±5%)
Consumption (MAX): 1200VA
Operation temperature: 10-35, or -20 to 40 when installed
in the Monsoon enclosure
Ingress protection rating: IP20, or IP54 with an optional
rain cover installed [certification in progress]
Dimensions (WxDxH): 491 x 310 x 396mm
Weight: 31kg
Laser safety features: Keyed interlock, emission delay,
magnetic interlock, scan-fail safety,
V-RAD 506 mechanical shutter | reaction time <20ms,
adjustable aperture masking plate. This laser system fully
complies with the latest EN 60825-1, FDA regulations and
TUV Laser Safety.
Colour
Red
Blue/Green
Wavelenght
637nm
455/525nm
Power
installed
6000mW
8000/
6000mW
Module
Type
RLM-6kF
BG-14kF
