The projector’s REMOTE Output isused todaisy-chain the
Remote signal when you want touse asingle Emergency
STOP Remote tocontrol multiple systems.
After a power failure or interlock failure (open circuit)
has occurred and been corrected you need to manually
reset laser emission bypressing the START button onthe
E-STOP Remote. Laser emission will then beavailable after
a60 second delay.
3. Safety key switch.
The Safety key must be inserted
and turned to ON position in order
toenable the system tooperate.
4. DMX Input/Through.
Use these ports to connect DMX
control signal or to daisy chain the
DMX signal between multiple laser
display systems.
5. Ethernet.
Use these ports to connect PCcontrol
signal or to daisy chain the control
signal between multiple laser display
systems.
6. FB4 laser control interface.
The inbuilt control interface allows
you to control the laser via Ethernet
and DMX/ArtNet, but italso handles all
the basic settings ofthe laser system
(master size and positions, method
of control, colour settings etc.). All
of these settings can be accessed
through the menu using the endless
rotary knob and once saved, they are
stored onincluded mini SDcard.
7. Colour Balance display mode
switch.
When the Colour Balance display
mode isactive, all the colours displayed
by laser will match those you see
on the screen in your laser software
(they can vary slightly, depending
onyour display and its colour settings).
The on& o setting ofColour Balance
mode is immediately stored in the
internal memory ofthe laser projector,
so next time you power it up, the
Colour Balance mode is set to its
latest state automatically.
i
The intent of laser manufactures is to produce a laser
diode driver with aslinear response behaviour aspossible,
sowhen the diode current increases, the optical power and
light intensity grow linearly. However, the human eye senses
brightness of light logarithmically over a moderate range
(Weber–Fechner law). Sowhen light intensity grows linearly,
human eye and brain doesn’tperceive itasalinear increase,
and our visual perception ofcolours changes.
Inthe world oflaser display systems this generates challenges
when wework with mixed colours (i.e. yellow, magenta etc.).
Normally the mixed colours coming out of laser systems
donot directly correspond with those wesee oncomputer
screens – because of the dierence in visual perception.
Inorder tosynchronise all the colours wesee onour screen
and those coming out ofthe laser device wedo,socalled,
palette calibration procedure inthe laser control software. This
can beofcourse rather lengthy process and even ifit’sdone
properly, the calibrated palette will always betied toparticular
control system or profile that was used during the colour
calibration and not tothe laser projector itself. Sowecame
with the idea tohard-code the “calibrated palette” into every
Spectrum laser system inour factory during the manufacture.
No matter what control interface you use or what control
signal is used (Ethernet, DMX, ILDA), the calibrated palette
isalways there, ready for you tobeswitched onbyColour
Balance button.
8. ILDA INPUT/OUTPUT.
ILDA INPUT connector isused for the
control signal input from an external
control interface. ILDA OUTPUT
connector is used to daisy chain the
control signal between multiple laser
systems.
9. Safety eyelet.
Use this together with appropriate
safety wire to secure the system
against unexpected fall.
