KVANT Spectrum Series Operational Manual

32  41
EN
KVANT Spectrum 30 ROGB – full colour, OPSL &
semiconductor diode laser system
Total Optical Power (installed): 30W
Total Optical Power (guaranteed): 30W*
*Due to Advanced Optical Correction technology used
in our laser systems the optical power output of each
laser colour within the system may slightly dier from the
specification ofrespective laser module(s) installed. This
does not aect the guaranteed total power output.
NOHD (Nominal Ocular Hazard Distance for guaranteed
power output): 3246 m
Beam diameter atlaser aperture: 7 × 7 mm
Beam divergence: 0,6 mrad (full angle)
Red: 0.4/0.3 mrad
Orange: 0.25 mrad
Green: 0.4/0.3mrad
Blue: 0.4/0.2 mrad
Modulation: 100 kHz | analog
Module cooling: TEC
Scanning System:
Juno 5 | 35kpps @ 8°, 60°
SATURN 5 | 48kpps@7°, 50° (optional)
Control signal: Ethernet, DMX/ArtNet, ILDA, SDcard (via
inbuilt FB4 control interface)
Power requirements: 100-240V/50-60Hz (±5%)
Consumption (MAX): 1200VA
Operation temperature: 10-35, or -20 to 40 when installed
in the Monsoon enclosure
Ingress protection rating: IP20, or IP54 with an optional
rain cover installed [certification in progress]
Dimensions (WxDxH): 491 x 310 x 396mm
Weight: 31kg
Laser safety features: Keyed interlock, emission delay,
magnetic interlock, scan-fail safety,
V-RAD 506 mechanical shutter | reaction time <20ms,
adjustable aperture masking plate. This laser system fully
complies with the latest EN 60825-1, FDA regulations and
TUV Laser Safety.
7.1
[ 30 ]
 
Colour
Red
Orange
Green
Blue
Wavelenght
637nm
590nm
525nm
462+455nm
Power
installed
6000mW
3000mW
10000mW
11000mW
Module
Type
RLM-6000L2
OPSL
GLM-10kF6
BLM-11kLD
