KVANT Spectrum 33 RYGB – full colour, OPSL &
semiconductor diode laser system
Total Optical Power (installed): 33W
Total Optical Power (guaranteed): 33W*
*Due to Advanced Optical Correction technology used
in our laser systems the optical power output of each
laser colour within the system may slightly dier from the
specification ofrespective laser module(s) installed. This
does not aect the guaranteed total power output.
NOHD (Nominal Ocular Hazard Distance for guaranteed
power output): 3406 m
Beam diameter atlaser aperture: 6 × 6 mm
Beam divergence: 0.6mrad (full angle)
Red: 0.55/0.4 mrad
Yellow: 0.25 mrad
Green: 0.4/0.3mrad
Blue: 0.4/0.2 mrad
Modulation: 100 kHz | analog
Module cooling: TEC
Scanning System:
Juno 5 | 35kpps @ 8°, 60°
SATURN 5 | 48kpps@7°, 50° (optional)
Control signal: Ethernet, DMX/ArtNet, ILDA, SDcard (via
inbuilt FB4 control interface)
Power requirements: 100-240V/50-60Hz (±5%)
Consumption (MAX): 1200VA
Operation temperature: 10-35, or -20 to 40 when installed
in the Monsoon enclosure
Ingress protection rating: IP20, or IP54 with an optional
rain cover installed [certification in progress]
Dimensions (WxDxH): 491 x 310 x 396mm
Weight: 31kg
Laser safety features: Keyed interlock, emission delay,
magnetic interlock, scan-fail safety,
V-RAD 506 mechanical shutter | reaction time <20ms,
adjustable aperture masking plate. This laser system fully
complies with the latest EN 60825-1, FDA regulations and
TUV Laser Safety.
[ 33 ]
Colour
Red
Yellow
Green
Green*
Blue
Wavelenght
637nm
577nm
532nm
525nm*
462+445nm
Power
installed
7000mW
5000mW
10000mW
10000mW*
11000mW
Module
Type
RLM-7000L
OPSL
LM-10kF6
OPSL*
BLM-11kLD
* available with additional fee
