© 2022 KVH Industries, Inc., All rights reserved. 54-1409 Rev. A
1
TracNet
™
H90
Installation Guide
This guide explains how to install the TracNet H90 hybrid VSAT, cellular, and Wi-Fi communications system. Operation
instructions are provided in the Quick Start Guide.
Table of Contents
Important Safety Information............................................. 2
Inspect Parts and Get Tools.............................................. 3
Plan the Antenna Installation ............................................. 4
Plan the BDU Installation................................................... 7
Prepare the Antenna Site .................................................. 8
Rig and Hoist the Antenna ................................................ 9
Prepare the Antenna Cable ............................................. 10
Wire the Antenna ............................................................. 11
Mount the Antenna .......................................................... 13
Mount the BDU................................................................ 15
Wire the BDU................................................................... 16
Connect an NMEA Talker ................................................ 17
Connect Power................................................................ 18
Turn On the System......................................................... 20
Configure the System ......................................................21
No-Transmit Zones (Optional)..........................................27
Test the System ...............................................................28
Connect Vessel Network Devices....................................29
Connect the Vessel Phones .............................................30
Educate the Customer .....................................................31
Appendices
Terminating LMR-240 Cable............................................32
Connecting Pigtail Cables to the Antenna Cable.............36
Approved Cable Types ....................................................37
Verifying the NMEA 0183 Message .................................38
Wiring Diagram ................................................................39
CAUTION - RF Radiation Hazard
The antenna transmits radio frequency (RF) energy
that is potentially harmful. Whenever the system is
powered on, make sure everyone stays more than
60.4 feet (18.4 m) away from the antenna. As
shown in the illustration, no hazard exists directly
below the antenna.
Who Should Install the System?
To ensure a safe and effective installation, only a KVH-
certified marine technician should install the system. To
find a technician near you, visit www.kvh.com/
wheretogetservice.
Technical Support
Within Continental U.S.A.: 1 866 701-7103
Worldwide: +1 401 851-3806
Email: mvbsupport@kvh.com
