4. Touchpad Electronic Deadbolt Installation
Feed power strip G through large square hole
of Power Board H and plug into the 6 prongs.
Line Power Board H up to the 3 small holes
drilled from the template. Verify that torque
blade engages with the T-turn and attach
power board with 3 chrome-colored screws.
5
Remove access cover I from Power Board H.
Hold as shown in photo and twist or pull up
on cover.
5 6 7 Install 4 new AA Alkaline batteries (not
included in package). Battery positions shown
on battery case. A series of quick beeps will
sound when batteries make complete contact.
Low Battery Indicator Light on the Power
Board will be lit when the batteries need to be
replaced.
Do not dispose of in fire, recharge, put in
backwards, disassemble, mix with used or
other battery types. May explode or leak and
cause personal injury.
8
