Kwikset Signature Series User Manual

2 / 4
Tighten screws evenly.
Install “L”
on exterior
assembly.
Do not
install “L.”
Install “P”
on exterior
assembly.
Install “P”
on exterior
assembly.
narrow
opening
wide
opening
a
b
c
21/8"
54 mm
11/2"
38 mm
Diameter is 21/8"
(54 mm)
Traditional Diameter is 11/2"
(38 mm)
Contemporary
oror
L
L
P P
M
N
C
J
V (2x)
V (2x)
E
E
Q
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (V).
Install exterior assembly and mounting plate.
C
Keep parallel to
edge of door.
Remove battery cover and battery pack from interior assembly. Install interior assembly onto mounting plate.
A B
a
c
b
d
If the turnpiece is pointing down (as
shown above), rotate the turnpiece
180° clockwise until you hear it click.
You may need to apply some force.
Make sure
turnpiece shaft is
rotated as shown.
Do not install
batteries
until step 5.
a
F
H
H
H
G
W
Remove key when
inished and make
sure the latch bolt
is fully extended.
W
(2x)
bottom
hole
b
If turnpiece shaft is not oriented
correctly, put the cover back on and
rotate the turnpiece as shown in step A.
What is the diameter of the hole in the door?
Install cylinder in exterior assembly.
A B
Traditional Traditional
Contemporary Contemporary
actual
size
V
actual
size
3
Install the exterior assembly and mounting plate
4
Install the interior assembly

Kwikset Signature Series Specifications

General

Keyway	KW1
Material	Metal
Finish	Satin Nickel, Venetian Bronze, Polished Brass
Security Grade	ANSI Grade 2
Re-key Technology	SmartKey
Compatibility	Standard doors
Strike Plate	Reinforced
Door Thickness	1-3/8" to 1-3/4"
Backset	Adjustable 2-3/8" or 2-3/4"
Handing	Reversible
Warranty	Limited Lifetime
