KYMCO 2 STROKE - BRAKE PAD WEAR; BRAKE SHOE WEAR

BRAKE PAD WEAR
• Check the wear indicator mark on each pad. If either pad
is worn to the wear indicator mark, replace both pads as
a set. See your authorized KYMCO dealer for this service.
BRAKE SHOE WEAR
• The rear brake is equipped with a brake wear indicator. When
the brake is applied, an arrow mark (1) attached to the brake
arm moves towards a reference mark (2) on the brake panel.
If the arrow mark aligns with the reference mark on full
application of the brake, the brake shoes must be replaced.
See your authorized KYMCO dealer for this service.
- 26 -
