BRAKE LEVER FREE PLAY INSPECTION & ADJUSTMENT
• The rear brake lever free play should be adjusted to 10-20mm
(0.4-0.8in) at the tip of the brake lever. If the free play is
incorrect, follow these instructions to adjust:
Turn the adjusting nut in direction (A) to decrease play, and in
direction (B) to increase play.
Turn the adjusting nut on the brake hub in direction (A) to decrease
Play, and in direction (B) to increase play
- 27 -
