Spark arrester cleaning
Be sure the exhaust pipe and muffler are cool
before cleaning the spark arrester.
1. Remove the bolt.
2. Remove the tailpipe by pulling it out of the
muffler.
3. Tap the tailpipe lightly, then use a wire brush
to remove any carbon deposits from the spark
arrester portion of the tailpipe.
4. Insert the tailpipe into the muffler and align
the screw holes.
5. Install the bolt and tighten it.
(1) Bolt
(1) Tailpipe (2) Spark arrester
(1)
(1)
(2)
140
