When using a constant-current
battery charger, use the follow-
ing Battery Charging Chart.
An overheated battery could
explode causing severe injury or
death. Always monitor charging
times and charge rates carefully.
Stop charging if the battery
becomes very warm to the touch.
Allow it to cool before resuming
charging.
The ATV comes equipped with a speci-
fied spark plug. See the specifications
chart for the correct spark plug. A light
brown insulator indicates that the plug
is correct. A white or dark insulator
indicates that the engine may need to
be serviced or the carburetor may need
to be adjusted. Consult an authorized
KYMCO ATV dealer if the plug insulator
is not a light brown color.
Never exceed the standard charg-
ing rate.
NOTE: If the battery voltage is
11.5 DC Volts or less, some charg-
ers may“cut off＂and fail to
charge. If this occurs, connect a
fully charged booster battery in
parallel (positive to positive and
negative to negative) for a short
period of time with the charger
connected. After 10-15 minutes,
disconnect the booster battery
leaving the charger connected and
the charger should continue to
charge. If the charger“cuts off,＂
replace the battery.
Connect the multimeter and test the
battery voltage. The meter should
read at least 12.5 DC Volts. If the
voltage is as specified, the battery
is ready for service.
Before installing the battery, make
sure the ignition switch is in the
OFF position.
Battery Charging Chart
(Constant-Current Charger)
74
When using an automatic bat-
tery charger, always follow the
charger manufacturer's instruc-
tions.
A.
B.
CAUTION
WARNING
After charging the battery for the
specified time, remove the battery
charger and allow the battery to sit
for 1-2 hours.
NOTE: If voltage in step 9 is
below specifications, charge the
battery an additional 1-5 hours;
then retest. Recheck electrolyte
level and the battery is ready for
service.
8.
9.
Place the battery in the battery
compartment; then coat the battery
posts and cable ends with a light
coat of multi-purpose grease.
10.
CAUTION
Connect the battery cables (positive
cable first); then install the battery
hold-down.
11.
Connecting cables in reverse (pos-
itive to negative and negative to posit-
ive) can cause serious damage to the
electrical system.
CAUTION
SPARK PLUG
