8-8
8.3.2. Engine oil replacement and oil filter
cleaning
A. Place the machine on a level place.
B. Warm up the engine for several minutes and stop it.
C. Place a container under the engine.
D. Remove the oil fill cap (1) and oil filter cap (2) to drain the
oil.
Be sure no foreign material enters the crankcase.
When removing the oil filter cap, the compression spring, oil
strainer and O-ring will fall out. Take care not to lose these parts.
To Next Page
