8-9
E. Clean the oil strainer with solvent.
F. Inspect the O-ring and replace if damaged.
G. Reinstall the O-ring, oil strainer, compression spring and
oil filter cap. Tighten the oil filter cap to specification.
Before reinstalling the drain plug, be sure to install the O-ring,
compression spring and oil strainer.
Tightening Torque
Oil filter cap (engine) 14.7 N-m (1.5 kgf-m, 11 lbf-ft)
H. Fill the engine with oil and install the oil fill cap.
Recommended oil: see CH 9.3
ENGINE OIL QUANTITY(550/700)
Periodic oil change
3.0L (2.64 lmp
qt,3.18 US qt)
2.4 L (2.11 Imp
qt, 2.54 US qt)
After draining and oil filter
cartridge change
3.2 L (2.82 lmp
qt,3.39 US qt)
2.6 L (2.29 lmp
qt, 2.76 US qt)
Total amount
3.6 L (3.17 lmp
qt,3.82 US qt)
2.9 L (2.64 Imp
qt, 3.07 US qt)
Be sure no foreign material enters the crankcase. Compression
spring and oil strainer.
I. Warm up the engine for several minutes at idle speed.
Check for oil leakage while warming up.
If oil leakage is found, stop the engine immediately and check
for the cause.
