Kyocera DF-770 - Document Finisher Unpacking Procedure

3NC/3NB/3NK
1-2-2
1-2-2 Unpacking
(1) Unpacking
Document Finisher
Figure 1-2-1
1
24
2
24
24
24
24
3
4
5
6
7
14
17
24
8
22
9
12
13
23
16
11
15
18 19 20 21
10
1. Skid
2. Bottom right pad
3. Bottom left pad
4. Document Finisher
5. Spacer A
6. Plastic sheet
7. Plastic sheet
8. Outer case
9. Upper right pad
10. Upper left pad
11. Spacer B
12. Finisher tray
13. Spacer C
14. Lower earth plate
15. Wire guide
16. Staple cartridge
17. Eject guide
18. M4 x 8 screw
19. M4 x 10 screw(black)
20. M4 x 30 screw
21. Upper earth plate
22. Connecting plate
23. Installation guide,etc.
24. Hinge joints
