3NC/3NB/3NK
1-6-1
1-6 Requirements on P WB Replacement
1-6-1 Remarks on finisher PWB replacement
When replacing the finisher PWB, remove the EEPROM (U4) from the finisher PWB that has been removed
and then reattach it to the new finisher PWB.
Figure 1-6-1
U4
DF main PWB
DF main PWB
