3NC/3NB/3NK
2-3-7
YC4
1 GND - - Ground
Connected to
the bridge
conveying
sensor 2
2 BRIDGE_SENS 2 I 0/5V DC BRCM2: On/Off
3+5V O5V DC
5 V DC power output to BRCS2
YC6
1 GND - - Ground
Connected to
the bridge
conveying
sensor 2 and
bridge cover
switch
2 BRIDGE_SENS 1 I 0/5V DC BRCS1: On/Off
3 +5V O 5V DC 5 V DC power output to BRCS1
4 GND - - Ground
5 BRIDGE_OPEN I 0/5V DC BRCUSW: On/Off
6 +5V O 5V DC 5 V DC power output to BRCUSW
7 NC - - Not used
YC7 1 BRIDGE1_B/ O 0/24V DC(pulse) BRCM1 control signal
Connected to
the bridge
conveying
motor1,2
2 BRIDGE1_A/ O 0/24V DC(pulse) BRCM1 control signal
3 BRIDGE1_B O 0/24V DC(pulse) BRCM1 control signal
4 BRIDGE1_A O 0/24V DC(pulse) BRCM1 control signal
5 BRIDGE2_B/ O 0/24V DC(pulse) BRCM2 control signal
6 BRIDGE2_A/ O 0/24V DC(pulse) BRCM2 control signal
7 BRIDGE2_B O 0/24V DC(pulse) BRCM2 control signal
8 BRIDGE2_A O 0/24V DC(pulse) BRCM2 control signal
Connector Pin Signal I/O Voltage Description
To Next Page
