Kyocera DF-770 - Page 91

3NC/3NB/3NK
2-3-9
YC3
1 PHADJ_MOT
2B
O 0/24V DC(pulse) PUSLM drive control signal
Connected to
the punch
slide motor
2 PHADJ_MOT
1B
O 0/24V DC(pulse) PUSLM drive control signal
3 PHADJ_MOT
2A
O 0/24V DC(pulse) PUSLM drive control signal
4 PHADJ_MOT
1A
O 0/24V DC(pulse) PUSLM drive control signal
YC4
1 PHMOT_N O 0/24V DC(pulse) PUM drive control signal
Connected to
the punch
motor
2 NC - - Not used
3 PHMOT_P O 0/24V DC(pulse) PUM drive control signal
YC5
124V2 O24V DC
24 V DC power output to PUSOL
Connected to
the punch
solenoid,
punch paper
edge
sensor1 and
punch tank
full sensor
2 PHSOL_PUL O 0/24V DC PUSOL: On/Off (activate)
3 PHSOL_RET O 0/24V DC PUSOL: On/Off (return)
4 PHLED_A O 0/3.3V DC PUPES1_A: On/Off
5 PHLED_B O 0/3.3V DC PUPES1_B: On/Off
6 PHLED_C O 0/3.3V DC PUPES1_C: On/Off
7 PHLED_D O 0/3.3V DC PUPES1_D: On/Off
8 PHLED_3.3V O 3.3V DC 3.3 V DC power output to PUPES1
9 5.0V O 5V DC 5 V DC power output to PUTFS
10 PHTNK_FUL I 0/5V DC PUTFS: On/Off
11
GND - - Ground
YC6
1 SEN O 3.3V DC 3.3 V DC power output to PUSLS
Connected to
the punch
slide sensor
2 GND - - Ground
3 PHADJ_HP I 0/3.3V DC PUSLS: On/Off
YC7
1 PHPES_DET I 0/3.3V DC PUPES2: On/Off
Connected to
the punch
paper edge
sensor 2
2 GND - - Ground
YC8
1 SENS3.3V O 3.3V DC 3.3 V DC power output to PUPS
Connected to
the punch
plus sensor
and punch
home posi-
tion sensor
2 GND - - Ground
3 PHMOT_PLS I 0/3.3V DC PUPS: On/Off
4 SENS3.3V O 3.3V DC 3.3 V DC power output to PUHPS
5 GND - - Ground
6 PHMOT_HP I 0/3.3V DC PUHPS: On/Off
Connector Pin Signal I/O Voltage Description
