Kyocera ECOSYS FS-C8525MFP Technical Reference Manual

Path Mode Graphics
2-33
Figure 2. 34. Clipping Rectangle Example
Printing with Character Paths
When a resident scalable (outline) font is selected, you can treat a character as a path and
add it to the current path. The PRESCRIBE command is CPTH (Character PaTH).
Paths created with the CPTH command can be either stroked or filled. See the following
example.
!R! RES;
UNIT P;
NEWP;
PAT 26;
SFNT ’Helvetica-Bd’, 54;
PMZP 72, 144;
CPTH "xyz";
FILL 1;
PAGE;
EXIT;
Figure 2. 35. Character Path
Line 2 of this program sets the unit to printing system’s points (1 point=
1
/
72
inch), then
the NEWP command on line 3 empties the current path (if any), making ready for con-
struction of a new path. The PAT command on line 4 selects predefined pattern number
26 as the current fill pattern.

Kyocera ECOSYS FS-C8525MFP Specifications

General

Category	Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Duplex Printing	Yes
Standard Paper Capacity	500 sheets
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Memory	1 GB
Memory (Maximum)	2 GB
Connectivity	USB 2.0, Ethernet
Print Speed	25 ppm
Print Resolution	600 x 600 dpi
Copy Speed	25 copies per minute
Fax Resolution	400 x 400 dpi
Max Paper Capacity	1, 600 sheets
Operating Systems Supported	Windows, Mac, Linux
Type	Multifunction
