Installing and Setting up the Machine > Part Names
Connectors/Interior
1 LINE Connector
2 TEL Connector
3 Option Interface
4 Network Interface Connector
5 USB Interface Connector
6 Envelope Lever (ECOSYS M3040idn and ECOSYS
M3540idn only)
7 Fuser Cover
8 Paper Width Guides
9 Support Tray Section of the Multi Purpose Tray
10 Multi Purpose Tray
11 Paper Length Guide
12 Paper Width Guides
13 Bottom Plate (ECOSYS M3040idn and ECOSYS
M3540idn only)
14 Size Dial
15 Duplex Cover
