2PX/2PY
1-5-39
7. Remove five screws and then remove
drum/developing drive unit.
8. Check or replace the drum/developing
drive unit and refit all the removed
parts.
Figure 1-5-59
Drum/Developing
drive unit
Screw
Screw
Screw
Screw
Screw
