Kyocera ECOSYS P3045dn Service Manual

2T6/2T7/2T8/2T9
2-3-9
YC12 1 +3.3V3_F2 O 3.3 V DC 3.3 V DC power output to EFS
Connected to
the eject full
sensor
2 GND - - Ground
3 PAPFULN I 0/3.3 V DC EFS: On/Off
YC13 1 LIFTMOTOR O 0/5 V DC LM: On/Off
Connected to
the lift motor
*: 60/55/50
ppm model
only
2 GND - - Ground
YC14 1 +3.3V9 O 3.3 V DC 3.3 V DC power output to LS
Connected to
the lift sensor
*: 60/55/50
ppm model
only
2 GND - - Ground
3 LSENS I 0/3.3 V DC LS: On/Off
YC15 1 +24V3_IL_F5 O 24 V DC 24 V DC power output to PM
Connected to
the polygon
motor
2 GND - - Ground
3 PLGDRN O 0/5 V DC PM: On/Off
4 PLGRDYN I 0/3.3 V DC PM ready signal
5 POLCLK O 0/3.3 V DC(pulse) PM clock signal
YC16 1 +5V3_F1 O 5 V DC 5 V DC power output to APCPWB
Connected to
the APC
PWB
2 VDATA1P O LVDS Video data 1 signal (+)
3 VDATA1N O LVDS Video data 1 signal (-)
4 VDATA2P O LVDS Video data 2 signal (+)
5 VDATA2N O LVDS Video data 2 signal (-)
6 SAMPLEN1 O 0/3.3 V DC Sample / hold signal 1
7 SAMPLEN2 O 0/3.3 V DC Sample / hold signal 2
8 OUTPEN O 0/3.3 V DC Laser enable
9 VCONT1 O Analog LD-1 Light volume adjustment
10 VCONT2 O Analog LD-2 Light volume adjustment
11 GND - - Ground
12 PDN I 0/3.3 V DC (pulse) Main scanning synchronizing signal
13 +3.3V3_F2 O 3.3 V DC 3.3 V DC power output to APCPWB
YC18 1 GND - - Ground
Connected to
the power
switch
2 POWERSW I 0/3.3 V DC PSSW: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P3045dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Internal memory	512 MB
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	52.8 dB
Sound pressure level (quiet mode)	51.5 dB
Sustainability certificates	ENERGY STAR
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Other operating systems supported	Android, iOS
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	285 mm
