Kyocera ECOSYS P3045dn Service Manual

2T6/2T7/2T8/2T9
2-3-12
YC20 51 C2P_SDAT I DC0V/3.3V Panel transmitted data signal
Connected to
the main
PWB
52 GND - - Ground
53 SDIF_SDCD O DC0V/3.3V Card detect signal
54 SDIF_INTA O DC0V/3.3V Interrupt signal
55 SDIF_CMD I/O DC0V/3.3V Command signal
56 BDN_D O DC0V/3.3V BD signal
57 SH2D I DC0V/3.3V Sample hold signal
58 GND - - Ground
59 LDOUT_2_DN I LVDS
60 LDOUT_2_DP I LVDS
YC21 1 TH3 I Analog FUTH2 output signal
Connected to
the fuser
thermistor
connect
PWB
2 TH1 I Analog FUTH1output signal
3 GND - - Ground
4 REARFANN O 24 V DC REFM: On/Off
5 +24V_F3 O 24 V DC 24 V DC power output to FTHPWB
YC22 1 +24V_F2 O 24 V DC 24 V DC power output to PF
Connected to
the paper
feeder
2 OPSDO O 0/3.3 V DC (pulse) PF communication serial data signal
3 OPSDI I 0/3.3 V DC (pulse) PF communication serial data signal
4 OPCLK O 0/3.3 V DC (pulse) PF communication serial clock signal
5 OPRDYN I 0/3.3 V DC Option communication ready signal
6 +3.3V3_F1 O 3.3 V DC 3.3 V DC power output to PF
7 GND - - Ground
8 OPSEL2 O 0/3.3 V DC PF select signal
9 OPSEL1 O 0/3.3 V DC PF select signal
10 OPSEL0 O 0/3.3 V DC PF select signal
11 OPPAUSEN O 0/3.3 V DC Paper stop signal
12 GND - - Ground
YC23 1 VBUS O 5 V DC 5 V DC power output to USB host
Connected to
the USB host
2 UDATAN I/O LVDS USB data signal (-)
3 UDATAP I/O LVDS USB data signal (+)
4 GND - - Ground
5 GND - - Ground
YC26 1 +3.3V_F2 O 3.3 V DC 3.3 V DC power output to ES
Connected to
the eject sen-
sor
2 GND - - Ground
3 EXITSENSN I 0/3.3 V DC ES: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P3045dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Internal memory	512 MB
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	52.8 dB
Sound pressure level (quiet mode)	51.5 dB
Sustainability certificates	ENERGY STAR
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Other operating systems supported	Android, iOS
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	285 mm
