Kyocera ECOSYS P3045dn Service Manual

2T6/2T7/2T8/2T9
2-3-11
YC20 17 GND - - Ground
Connected to
the main
PWB
18 USBH_DP3 I/O Analog
19 USBH_DN3 I/O Analog
20 GND - - Ground
21 SDIF_DAT0 I/O DC0V/3.3V
22 SDIF_DAT1 I/O DC0V/3.3V
23 SDIF_DAT2 I/O DC0V/3.3V
24 SDIF_DAT3 I/O DC0V/3.3V
25 SDIF_SDCLK I DC0V/3.3V
26 GND - - Ground
27 SH1D I DC0V/3.3V
28 GND - - Ground
29 LDOUT_1_DN I LVDS
30 LDOUT_1_DP I LVDS
31 GND - - Ground
32 GND - - Ground
33 GND - - Ground
34 GND - - Ground
35 GND - - Ground
36 GND - - Ground
37 GND - - Ground
38 GND - - Ground
39 LVU_SLEEP_
N
I DC0V/3.3V
40 POWER_SW O DC0V/3.3V
41 E2C_IRN O DC0V/3.3V
42 E2C_WKUP_
BGD_N
O DC0V/3.3V
43 ENG_HLDN I DC0V/3.3V
44 C2E_QUICK_
START
I DC0V/3.3V
45 PVSYNC O DC0V/3.3V VSYNC
46 GND - - Ground
47 P2C_WKUP_
RDY
O DC0V/3.3V
48 ENERGYSAV
ERKEY_N
O DC0V/3.3V
49 C2P_RST_N I DC0V/3.3V Panel reset signal
50 P2C_SDAT O DC0V/3.3V Panel received data sjgnal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P3045dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Internal memory	512 MB
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	52.8 dB
Sound pressure level (quiet mode)	51.5 dB
Sustainability certificates	ENERGY STAR
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Other operating systems supported	Android, iOS
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	285 mm
