Kyocera ECOSYS P3045dn Service Manual

2T6/2T7/2T8/2T9-2
1-4-25
Code Contents Verification procedure & check point Remarks ECOSYS P3060dn/P3055dn/P3050dn/P3045dn
― It locks on a Welcome screen.It locks on a start-
ing logo (Taskalfa/Ecosys) screen.(Even if time
passes for a definite period of time in more than
* notes, a screen does not change)
(1) Check the harness, and the connection state of a connector between
Panel<=>Main boards, and perform an operation check.
(2) Check contact of a DDR memory (extracting) and perform an operation check.
If exchangeable, it will exchange and will perform an operation check.
(3) U021 Controller backup initialization is carried out and an operation check is
performed.
(4) Exchange a PanelMain board and perform an operation check.
(5) Exchange a Main board and perform an operation check.
(6) It will get, if USBLOG is obtainable, and contact service headquarters.
1. Panel <=> Main IF
(Engine PWB Relay)
Main PWB: YC2
Engine PWB: YC20,YC30
Panel PWB: YC1
2. DDR memory
Main PWB: YS1
* note: 60[s]
F000 CF000 will be displayed if * notes progress is
carried out for a definite period of time with a
Welcome screen.The communication fault
between Panel-Main boardsCommunication
fault between Panel Core-Main Core Notes 2
(1) Check the harness, and the connection state of a connector between
Panel<=>Main boards, and perform an operation check.
(2) Check contact of a DDR memory (extracting) and perform an operation check.
If exchangeable, it will exchange and will perform an operation check.
(3) U021 Controller backup initialization is carried out and an operation check is
performed.
(4) Exchange a Main board and perform an operation check.
(5) Exchange a PanelMain board and perform an operation check.
(6) It will get, if USBLOG is obtainable, and contact service headquarters.
1. Panel <=> Main IF
(Engine PWB Relay)
Main PWB: YC2
Engine PWB: YC20,YC30
Panel PWB: YC1
2. DDR memory
Main PWB: YS1
* note: 60[s]
F15X Abnormality detecting in an authentication
device control section
(1) Check the harness between authentication device <=>Main boards, and the
connection situation of a connector, and perform an operation check.
(2) Carry out U021 Main backup initialization and perform an operation check.
(3) Exchange a Main board and perform an operation check.
(4) Get USBLOG and contact service headquarters.
1.Authentication device <=> Main IF
Main PWB: YC6
Authentication device: IC card reader
etc.
[Main body <=> authentication device]
USB-HOST connector
[Main boad <=> USB connector]
Main boad: YC510
F17X Abnormality detecting in a printer data control
part
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
F18X Abnormality detecting in a Video control section (1) Check the harness between Engine<=>Main boards, and the connection state
of a connector, and perform an operation check.
(2) U021 Controller backup initialization is carried out and an operation check is
performed.
(3) Exchange an Engine board and perform an operation check.
(4) Exchange a Main board and perform an operation check.
(5) Get USBLOG and contact service headquarters.
F1DX Abnormality detecting of the image memory
Management Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
* Poor arrangement of F1D4:Random
Access Memory(1) Confirmation of
U340(2) Initialization of a set point
(U021)
F21X Abnormality detecting in an image-processing
part
(1) Check contact of a DDR memory and perform an operation check.
(2) Carry out U021 Main backup initialization and perform an operation check.
(3) Exchange a Main board and perform an operation check.
(4) Get USBLOG and contact service headquarters.
F22X
F23X
F24X Abnormality detecting in the system Manage-
ment Department
(1) Check contact of a DDR memory and perform an operation check.
(2) Carry out U021 Main backup initialization and perform an operation check.
(3) Exchange a Main board and perform an operation check.
(4) Get USBLOG and contact service headquarters.
* F248 is the abnormalities of a printer
process.In recurring by specific printer
data, please give me cooperation at
acquisition of capture data and
USBLOG.
[Controller failure]
Turn power on and off to clear.
USB log is required for investigation.
[Main PWB]
There is no hard components that can be checked in the
field.

Kyocera ECOSYS P3045dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Internal memory	512 MB
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	52.8 dB
Sound pressure level (quiet mode)	51.5 dB
Sustainability certificates	ENERGY STAR
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Other operating systems supported	Android, iOS
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	285 mm
