Kyocera ECOSYS P3045dn Service Manual

2T6/2T7/2T8/2T9
1-4-26
F25X Abnormality detecting in a network manage-
ment department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
* It may occur according to a visitor's
network environment.
[Main body <=> External network]
Ethernet network
F26X Abnormality detecting in the system Manage-
ment Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
F27X
F28X
F29X
F2AX
F2BX Abnormality detecting in a network control part (1) Carry out U021 Main backup initialization and perform an operation check.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
(Depending on an analysis result, it is packet capture acquisition)
[Main body <=> External network]
Ethernet network
F2CX
F2DX
F2EX
F2FX
F30X
F31X
F32X
F35X Abnormality detecting in the printing controlling
Management Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
F38X Abnormality detecting in the authentication
authorized Management Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
[Main body <=> authentication device]
USB-HOST connector
[Main boad <=> USB connector]
Main boad: YC510
F3AX Abnormality detecting in the Entity Manage-
ment Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
F3BX
F3CX
F3DX
F3EX
F3FX
F40X
F41X
F43X
F44X
F45X
F46X Abnormality detecting of a printer rendering part (1) Exchange boards and perform an operation check.
(2) the acquisition wish of USBLOG -- carry out
(Depending on the (2) case, it is print capture data acquisition)
* F46F is the abnormalities of a printer
process.In recurring by specific printer
data, please give me cooperation at
acquisition of capture data and
USBLOG.
Code Contents Verification procedure & check point Remarks ECOSYS P3060dn/P3055dn/P3050dn/P3045dn

Kyocera ECOSYS P3045dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Internal memory	512 MB
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	52.8 dB
Sound pressure level (quiet mode)	51.5 dB
Sustainability certificates	ENERGY STAR
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Other operating systems supported	Android, iOS
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	285 mm
