Kyocera ECOSYS P3045dn Service Manual

2T6/2T7/2T8/2T9
1-4-27
F4DX Abnormality detecting in the Entity Manage-
ment Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
[Main PWB]
There is no hard components that can be checked in the
field.
F4EX
F4FX Abnormality detecting in the JOB Management
Department
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
Since the USB log immediately after
occurrence is needed for analysis,
please give me cooperation of acquisi-
tion.
F52X Abnormality detecting in a JOB execution part "(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
Since the USB log immediately after
occurrence is needed for analysis,
please give me cooperation of acquisi-
tion.
F53X
F55X
F56X
F57X
F61X Abnormality detecting in a report creation part (1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
Since the USB log immediately after
occurrence is needed for analysis,
please give me cooperation of acquisi-
tion.
[Controller failure]
Turn power on and off to clear.
USB log is required for investigation.
F63X Abnormality detecting in a device control sec-
tion
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
F68X Abnormality detecting in a storage device con-
trol section
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
* F684 is the overwrite error at the time
of an HDD security kit.
F90X Abnormality detecting in the extension applica-
tion service part
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
Since the USB log at the time of occur-
rence is needed for analysis, please
give me cooperation of acquisition.
F93X Abnormality detecting in the extension applica-
tion management part
(1) U021 Controller backup initialization is carried out and an operation check is
performed.
(2) Exchange a Main board and perform an operation check.
(3) Get USBLOG and contact service headquarters.
Since the USB log at the time of occur-
rence is needed for analysis, please
give me cooperation of acquisition.
Code Contents Verification procedure & check point Remarks ECOSYS P3060dn/P3055dn/P3050dn/P3045dn

Kyocera ECOSYS P3045dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Internal memory	512 MB
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	52.8 dB
Sound pressure level (quiet mode)	51.5 dB
Sustainability certificates	ENERGY STAR
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Other operating systems supported	Android, iOS
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	285 mm
