Kyocera ECOSYS P4035dn

2P7/2R0/3PN
1-5-33
11. Remove two screws.
12. Release the hook A by twisting right
upper cover.
13. Release two hooks B by sliding the right
upper cover upward and then remove it.
Figure 1-5-59
14. Remove three screws.
15. Release two hooks by sliding the right
lower cover upward and then remove it.
Figure 1-5-60
Right upper cover
Front cover
Screw
Screw
Hooks B
Hook A
Right lower
cover
Screw
Screw
Screw
Hooks
