2P7/2R0/3PN-3
1-1-2
Paper
Capacity
Cassette
500 sheets (80 g/m2)
MP Tray
100 sheets (A4, 80 g/m2) / 20 sheets (A3, 80 g/m2)
Output Tray
Capacity
Top Tray
500 sheets (A4, 80 g/m2) / 450 sheets (A3, 80 g/m2)
Face-up Tray
250 sheets (A4, 80 g/m2)
Photoconductor a-Si drum (diameter 30 mm)
Image Write System Semiconductor laser and electrophotography
Charging system Contact charger roller method
Developer system Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system Transfer roller method
Separation system Small diameter separation, dischager needle (DC bias)
Cleaning system Counter blade cleaning + cleaning roller
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system Heat and pressure fusing with the heat roller and the press roller
Heat source: halogen heater
Abnormally high temperature protection devices: thermostat
Duplex system Stack-less system at Built-in type
Continuous printing 1 to 999 sheets
Resolution Fine 1200 mode, Fast 1200 mode, 600 dpi, 300 dpi
Operation
Environment
Temperature 10 to 32.5 °C (50 to 90.5 °F)
Relative
Humidity
15 to 80 %
Altitude 2,500 m (8,202 feet) maximum
Illumination 1,500 lux maximum
Controller PowerPC465, ARM7/ARM9
Operating Systems
Windows XP, Windows Vista, Windows Server 2008/R2, Windows 7,
Windows Server 2012/R2, Windows 8, Windows 8.1,
Apple Macintosh OS 10.5 or later
Interface Standard USB Interface Connector: 1
USB Host: 2
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
eKUIO slot:1
Option HD-6/HD-7, IB-50, IB-51, IB-32
PDL PRESCRIBE
Emulation PCL6, IBM Proprinter, EPSON LQ-850, Line Printer, KPDL, KPDL(Auto)
Memory
Standard:256 MB, Maximum:1280 MB
Dimensions (W × D × H) 469 × 410 × 320 mm
18 7/16 × 16 1/8 × 12 5/8"
Weight 20.0 kg or less/44.0 lbs or less (without toner container)
Item Description
Model ECOSYS P4035dn ECOSYS P4040dn
