2P7/2R0/3PN
1-5-65
4. Pull out the cassette.
Figure 1-5-119
5. Remove two screws.
6. Release the hook A by twisting right
upper cover.
7. Release two hooks B by sliding the right
upper cover upward and then remove it.
Figure 1-5-120
Cassette
Printer
Right upper cover
Front cover
Screw
Screw
Hooks B
Hook A
