2P7/2R0/3PN
2-3-3
YC2
A13 C2P_LCDCO
N
O 0/3.3 V DC Panel LCD control signal
Connected to
the engine
PWB
B13 P2C_PKEY I 0/3.3 V DC Panel start signal
A14 C2P_BUZCO
N
O 0/3.3 V DC Panel buzzer control signal
B14 FUPRST O 0/3.3 V DC Panel reset signal
A15 GND - - Ground
B15 GND - - Ground
A16 VBUS O 5V DC 5 V DC power output to USB
B16 UDATAP I/O - USB data signal
A17 GND - - Ground
B17 UDATAN I/O - USB data signal
A18 GND - - Ground
B18 GND - - Ground
A19 +5V2 I 5 V DC 5 V DC power input from EPWB
B19 +5V2 I 5 V DC 5 V DC power input from EPWB
A20 +5V2 I 5 V DC 5 V DC power input from EPWB
B20 +5V2 I 5 V DC 5 V DC power input from EPWB
YC5
1 VDD5 O 5 V DC 5 V DC power output to eKUIO
Connected to
the eKUIO IF
2 GND - - Ground
3 RESETN O 0/3.3 V DC Reset signal
4 VDD5_CUT O 0/3.3 V DC Sleep signal
5 GND - - Ground
6 WAKEUP I 0/3.3 V DC Wake-up signal
7 AUDIO I 0/3.3 V DC Audio signal
8 NC - - Not used
9 NC - - Not used
10 NC - - Not used
11 GND - - Ground
12 NC - - Not used
13 NC - - Not used
14 GND - - Ground
15 NC - - Not used
16 NC - - Not used
17 GND - - Ground
18 USB_DP I/O - USB data signal
19 USB_DN I/O - USB data signal
20 VBUS O 5 V DC 5 V DC power output to eKUIO
Connector Pin Signal I/O Voltage Description
