Kyocera ECOSYS P4035dn User Manual

2P7/2R0/3PN
2-3-4
YC6
1 +3.3V O 3.3 V DC 5 V DC power output to OP
Connected to
the centro
option I/F
2 +5.0V O 5 V DC 5 V DC power output to OP
3 P1284DIR O 0/3.3 V DC Direction input signal
4 NACK O 0/3.3 V DC Acknowledge input signal
5 BUSY O 0/3.3 V DC Busy input
6 PERROR O 0/3.3 V DC Errer signal
7 SELECT O 0/3.3 V DC Select signal
8 NFAULT O 0/3.3 V DC Errer signal
9 PDATA1 I/O - Data signal
10 PDATA2 I/O - Data signal
11 PDATA3 I/O - Data signal
12 PDATA4 I/O - Data signal
13 PDATA5 I/O - Data signal
14 PDATA6 I/O - Data signal
15 PDATA7 I/O - Data signal
16 PDATA8 I/O - Data signal
17 NSELECTIN I 0/3.3 V DC Select signal
18 NSTROBE I 0/3.3 V DC Output signal
19 NAUTOFD I 0/3.3 V DC AUTO-FEED signal
20 NINIT I 0/3.3 V DC Reset signal
21 PDETECT I 0/3.3 V DC OP detection signal
22 GND - - Ground
YC8
1 TD1+ I/O 0/3.3 V DC(pulse) Trancemitted data
Connected to
the network I/
F
2 TD1- I/O 0/3.3 V DC(pulse) Send data
3 TD2+ I/O 0/3.3 V DC(pulse) Send data
4 TD2- I/O 0/3.3 V DC(pulse) Send data
5 CT1 O 3.3 V DC 3.3 V DC power output
6 CT2 O 3.3 V DC 3.3 V DC power output
7 TD3+ I/O 0/3.3 V DC(pulse) Send data
8 TD3- I/O 0/3.3 V DC(pulse) Send data
9 TD4+ I/O 0/3.3 V DC(pulse) Send data
10 TD4- I/O 0/3.3 V DC(pulse) Send data
11 GRLED_A I 0/3.3 V DC LED flashing caution signal
12 GRLED_K I 0/3.3 V DC LED flashing caution signal
13 YWLED_A I 0/3.3 V DC LED flashing caution signal
14 YWLED_K I 0/3.3 V DC LED flashing caution signal
Connector Pin Signal I/O Voltage Description
