Kyocera ECOSYS P6030cdn Service Manual

2K8
1-3-5
Detail of service status page (2)
Service items Description
Code conversion
ABCDEF GHI J
0123456789
No. Items Description
 NVRAM version _ 1F3 1225 _ 1F3 1225
(a) (b) (c) (d) (e) (f)
a) Consistency of the present software version and the database
_ (underscore): OK
* (Asterisk): NG
(b) Database version
(c) The oldest time stamp of database version
(d) Consistency of the present software version and the ME firmware ver-
sion
_ (underscore): OK
* (Asterisk): NG
(e) ME firmware version
(f) The oldest time stamp of the ME database version
Normal if (a) and (d) are underscored, and (b) and (e) are identical with (c)
and (f).
 Mac address -
 Destination information -
 Area information -
 Margin settings Top margin/Left margin
 Low Power mode settings -
 Top offset for each paper
source
MP tray/Paper feeder 1/Paper feeder 2/Paper feeder 3/ - /Duplex/
Page rotation
 Left offset for each paper
source
MP tray/Paper feeder 1/Paper feeder 2/Paper feeder 3/ - /Duplex/
Page rotation
 L value settings Top margin (integer)/Top margin (decimal place)/Left margin (integer)/Left
margin (decimal place)/Paper length (integer)/Paper length (decimal place)/
Paper width (integer)/Paper width (decimal place)/

Life counter (The first line)
Machine/MP tray/Printer’s cassette/Paper feeder 1/Paper feeder 2/
Paper feeder 3/ - /Duplex printing
Life counter (The second
line)
Drum unit K/Drum unit C/Drum unit M/Drum unit Y/
Intermediate transfer unit/Developing unit K/Developing unit C/
Developing unit M/Developing unit Y/Maintenance kit
 Operation panel lock status 0: Off
1: Partial lock
2: Full lock
 USB information 0: Not connected
1: Full-Speed
2: Hi-Speed
 Paper handling information 0: Paper source unit select
1: Paper source unit
 Color printing double count
mode
0: All single counts
3: Folio, Single count, Less the 330 mm (length)
 Black and white printing
double count mode
0: All single counts
3: Folio, Single count, Less the 330 mm (length)

Kyocera ECOSYS P6030cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2150 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	34.4 dB
Sound pressure level (printing)	52.5 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	76 W
Power consumption (printing)	529 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	480 mm
