Kyocera ECOSYS P6030cdn Service Manual

2K8
1-3-9
Write data (USB memory data write)
Description
To write data into a USB memory.
Procedure
Install the USB memory before attempting to write data.
1. Enter the service mode [>>Write Data].
2. Press the OK key. [>>Write Data?] will be displayed.
3. Press the OK key. [Data waiting] is displayed and the printer waits for data to be writ-
ten.
4. When the data is sent, [Processing] appears and the data is written to USB memory.
When data writing ends, the display returns to [Ready].
Completion
Counter reset for the maintenance kit
Description
The "Install MK" message means that maintenance kit should be replaced at 200,000 pages
of printing. The interval counter must be manually reset using this service item.
Maintenance kit includes the following units:
Drum unit × 4
Developing unit M, C, Y and K
Fuser unit
Intermediate transfer unit
Paper feed roller assembly
Retard roller assembly
Ozone filter
Purpose
To reset the life counter for the drum units, developing units, intermediate transfer unit, and
fuser unit included in maintenance kit.
Procedure for replacing the maintenance kit
Drum unit × 4 (See page 1-5-14)
Developing unit M, C, Y and K (See page 1-5-12)
Fuser unit (See page 1-5-25)
Intermediate transfer unit (See page 1-5-16)
Paper feed roller assembly (See page 1-5-8)
Retard roller assembly (See page 1-5-10)
Ozone filter (See page 1-5-39)
Procedure
1. Enter the service mode [>>Maintenance].
2. Press the OK key. [>>Maintenance?] will be displayed.
3. Press the OK key twice. The counter for each component is reset immediately.
Completion
Note:
Occurrences of resetting the maintenance kits are recorded on the service status page in
number of pages at which the maintenance kit was replaced (See page 1-3-2).
This may be used to determine the possibility that the counter was errorneously or uninten-
tionally reset.
Service items Description
>>Write Data
>>Maintenance

Kyocera ECOSYS P6030cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2150 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	34.4 dB
Sound pressure level (printing)	52.5 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	76 W
Power consumption (printing)	529 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	480 mm
