Kyocera FS-1040 - Front Printer Components; Rear Printer Components

1-2
Machine Parts
Front Printer Components
1 Top Tray
2 Paper Stopper
3 Front Cover
4 Manual Feed Tray (FS-1060DN/FS-1061DN)
5 Cassette Cover
6 Cassette
7 Operation Panel
8 Main Power Switch (For Korean models)
9 Power Switch
Rear Printer Components
10 Top Cover
11 Rear Cover
12 Power Cord Connector
13 Network Interface Connector (FS-1060DN/FS-1061DN)
14 USB Interface Connector
1
3
5
7
9
2
4
6
8
12
10
13
11
14
* The illustration shows the FS-1060DN/FS-1061DN.
