Kyocera FS-1040 - Rear Cover

5-9
Troubleshooting
Rear Cover
Follow the steps below to clear paper jams inside the rear cover.
Note When the front cover is opened or closed, the paper inside
the machine may be discharged.
1
2
1
2
4
1
2
3
(FS-1060DN/FS-1061DN
only)
IMPORTANT Take care not to
touch the drum and transfer
roller (black).
Drum
Transfer Roller
