Kyocera FS-1350DN User Manual

Connecting and Printing 4-15
Custom Mode
When selecting Custom Mode, printer port and utilities are changed
as necessary.
1 On Installation Method screen, click Custom Mode.
2 On Driver tab and Utility tab of the Custom Installation screen, select
the printer driver and utilities you want to install, and click Next.
3 Select the printer you want to install, and click Next.
4 Confirm the settings and click Install. Printer driver installation
starts.
5 Installation Completed screen appears. Click Finish to return to the
main menu.
Note When you want to add or edit the port connected to the
printer, select the printer and Custom Select, then click Next.
Add Standard TCP/IP Printer Port Wizard appears. Follow the
steps in the wizard to add or edit the port.
Note During any point in the installation process, if the
Windows Security warning dialog box appears, click Install
this driver software anyway.
If the Hardware Installation screen appears in Windows XP,
click Continue Anyway.

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
