4-20 Connecting and Printing
Status Monitor
The Status Monitor monitors the printer status and provides an ongoing
reporting function. It also allows you to specify and modify settings for
printers not included in the KX Driver.
The Status Monitor is installed automatically during KX Driver
installation.
Accessing the Status Monitor
Use either of the methods listed below to launch the Status Monitor.
Launch when printing starts:
When you specify a printer and start a print job, one Status Monitor
is launched for each printer name. If Status Monitor startup is
requested from multiple printers, Status Monitors are launched for
each printer that issues the request.
Launch from the KX Driver properties:
Right-click the Version Info button in the KX Driver Properties dialog
box. Then click Status Monitor in the Version Info dialog box to
launch the Status Monitor.
Exiting the Status Monitor
Use either of the methods listed below to exit the Status Monitor.
Exit manually:
Right-click the Status Monitor icon in the taskbar and select Exit in
the menu to exit the Status Monitor.
Exit automatically:
The Status Monitor automatically shuts down after 5 minutes if it is
not being used.
Screen Overview
The screen overview of the Status Monitor is as follows.
Pop-up window
If an information notification event occurs, a pop-up window appears.
This window only appears when the 3D View is open on the desktop.
3D View
This shows the status of the monitored printer as a 3D image. You can
choose whether to show or hide the 3D view from the menu displayed
when you right-click the Status Monitor icon.
Pop-up window
3D View
Status Monitor icon

Table of Contents

Other manuals for Kyocera FS-1350DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-1350DN and is the answer not in the manual?

Kyocera FS-1350DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Processor modelPowerPC–440F5
Maximum internal memory1152 MB
Sound power level (standby)30 dB
Sound pressure level (printing)54 dB
Power supply typeAC 220 - 240 V, 50/60 Hz
Capacity cartridge7200 sheets
Standard media sizes(105 x 148 - 216 x 297 mm)
Power consumption (active)484 W
Compliance industry standardsTUV/GS, CE
Number of print cartridges1
Total input capacity250 sheets
Maximum input capacity800 sheets
Maximum print size216 x 356 mm
Non-ISO print media sizesFolio (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Power consumption (standby)12 W
Power consumption (PowerSave)7.1 W
DisplayLCD
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)375 x 393 x 267 mm
