Kyocera FS-1350DN User Manual

Maintenance 5-7
4 Place the drum unit flat on a clean, level surface.
5 Use a clean, lint free cloth to clean dust and dirt away from the metal
registration roller.
6 On the drum unit, slide the charger cleaner (green) back and forth 2
or 3 times to clean the charger wire, then return it to its original
position (CLEANER HOME POSITION).
7 When cleaning is complete, return the drum unit to the original
position.
IMPORTANT Do not place the drum unit on end.
IMPORTANT Take care not to touch the transfer roller (black)
during cleaning.
IMPORTANT Remove the fixing tape on the charger cleaner in
case of the first cleaning.
After cleaning, make sure you restore the charger cleaner to its
home position.

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
