Paper Handling 1-9
Envelopes
Up to 5 envelopes can be loaded at a time. Envelopes should be fed in
the face-up position, right edge first.
Since the composition of an envelope is more complex than that of
ordinary paper, it is not always possible to ensure consistent printing
quality over the entire envelope surface.
Normally, envelopes have a diagonal grain direction. Refer to Paper
Grain on page 1-6. This direction can easily cause wrinkles and creases
when envelopes pass through the printer. Before purchasing envelopes,
make a test print to check whether the printer accepts the envelope.
Do not use envelopes that have an encapsulated liquid adhesive.
Avoid a long printing session for envelopes only. Extended envelope
printing can cause premature printer wear.
If jams occur, try setting less envelopes on the MP tray.
To avoid jams caused by curled envelopes, stack no more than 10
printed envelopes on the output tray.
Thick Paper
Fan the stack of paper and align the edges before loading them in the
MP tray. Some types of paper have rough edges on the back (those are
created when the paper is cut). In this case, put the paper on a flat place
and rub the edges once or twice with, for example, a ruler to smooth
them. Feeding rough edged paper may cause paper jams.
Colored Paper
Colored paper should satisfy the same conditions as white bond paper.
Refer to Paper Specifications on page 1-2. In addition, the pigments
used in the paper must be able to withstand the heat of fusing during the
printing process (up to 200 °C or 392 °F).
Preprinted Paper
Preprinted paper should satisfy the same conditions as white bond
paper. Refer to Paper Specifications on page 1-2.The preprinted ink
must be able to withstand the heat of fusing during the printing process,
and must not be affected by silicone oil.
Do not use paper with any kind of surface treatment, such as the type of
paper commonly used for calendars.
Note If the paper jams
even after you smooth it
out, load the paper in
the MP tray with the
leading edge raised up
a few millimeters as
shown in the
illustration.

Table of Contents

Other manuals for Kyocera FS-1370DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-1370DN and is the answer not in the manual?

Kyocera FS-1370DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Memory typeDDR
Memory slots1
Processor model440F5
Processor familyPowerPC
Maximum internal memory1152 MB
Sound power level (standby)30 dB
Sound pressure level (printing)55 dB
Sound pressure level (quiet mode)49 dB
Total input capacity300 sheets
Maximum input capacity800 sheets
Total number of input trays2
Maximum number of input trays4
Multi-Purpose tray input capacity50 sheets
Mobile printing technologiesNot supported
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)11 W
Power consumption (printing)554 W
Power consumption (PowerSave)5.5 W
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle2800 pages per month
Page description languagesEpson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
DisplayLCD
CertificationGS, TUV, CE
Product colorBlack, White
Custom media width70 - 215.9 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Duplex media weight60 - 105 g/m²
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth393 mm
Width375 mm
Height267 mm
