2-68 Using the Operation Panel
Service (for maintenance)
The options available in Service are as follows:
Print Status Page (Printing the service status page)
Print Network Status Page (Printing the network status page)
Print Test Page
Developer (Initializing the developer unit)
1 Press Z while Adjust/Maintenance > is displayed.
2 Press U or V repeatedly until >Service > appears.
Print Status Page (Printing the service status page)
The service status page contains printer settings information that is more
detailed than the standard status page and is therefore mostly for service
purposes. However, there is a great deal of information on the service
status page that may be useful to you.
1 Press Z while >Service > is displayed.
2 Press U or V repeatedly until >>Print Status Page appears.
3 Press [OK]. A question mark (?) appears.
4 Press [OK] again. Processing appears and a service status page
is printed out.
5 When printing ends, the display returns to Ready.
Print Network Status Page (Printing the network status page)
The network status page contains detailed information on the network
settings. This is primarily used for maintenance by service
representative, but it contains information that may also be useful to you.
1 Press Z while >Service > is displayed.
2 Press U or V repeatedly until >>Print Network Status Page
appears.
3 Press [OK]. A question mark (?) appears.
4 Press [OK] again. Processing appears and a network status page
is printed out.
5 When printing ends, the display returns to Ready.
Print Test Page
The test page is printed to check the effectiveness of printer
adjustments. This is primarily used for maintenance by service
representative, but it contains information that may also be useful to you.
1 Press Z while >Service > is displayed.
IMPORTANT Service is primarily a menu used by service
representative for maintenance work. There is no need for customers
to use this menu.
>Service >
>>Print Status Page ?
>>Print
Network Status Page?

Table of Contents

Other manuals for Kyocera FS-1370DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-1370DN and is the answer not in the manual?

Kyocera FS-1370DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Memory typeDDR
Memory slots1
Processor model440F5
Processor familyPowerPC
Maximum internal memory1152 MB
Sound power level (standby)30 dB
Sound pressure level (printing)55 dB
Sound pressure level (quiet mode)49 dB
Total input capacity300 sheets
Maximum input capacity800 sheets
Total number of input trays2
Maximum number of input trays4
Multi-Purpose tray input capacity50 sheets
Mobile printing technologiesNot supported
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)11 W
Power consumption (printing)554 W
Power consumption (PowerSave)5.5 W
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle2800 pages per month
Page description languagesEpson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
DisplayLCD
CertificationGS, TUV, CE
Product colorBlack, White
Custom media width70 - 215.9 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Duplex media weight60 - 105 g/m²
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth393 mm
Width375 mm
Height267 mm
