Device Settings
Not all installed devices are detected by using Auto Configure. Before
selecting OK in the Device Settings tab, check the settings to make sure that
they are correct.
Note: The default setting for Windows XP Service Pack 2 is for the Windows
Firewall to be set to On. The setting can be changed to allow communication
between the printing system and your computer. In the Windows Security
Alert dialog box, click Unblock.
Silent Auto Configure
Silent Auto Configure checks the printing system every 10 minutes for
changes in optional devices or memory. When a change is detected, the driver
is automatically updated with the new settings. Silent Auto Configure is only
available for printing systems installed on Windows Vista OS.
In a client/server environment, this feature is unavailable to a client logged in as
a restricted user.
Enabling Auto Configuration
The Auto Configure button can be used to detect all available device options
when the printing system is connected to a network through a TCP/IP port.
1
Verify that all optional devices are attached to the printing system, and that it is
turned on and ready to print.
2
In the Device Settings tab, click Auto Configure.
In Windows 2000 and Windows XP, the driver settings are updated
immediately.
In Windows Vista, the Auto Configure dialog box opens. Select from Auto
configure options:
Auto Configure Now
Click the button at any time to retrieve the current settings from the printing
system. It is recommended to do this when the driver is first installed and
when Silent auto configuration is turned off.
Silent auto configuration
Select to let the driver check the printing system every 10 minutes for any
changes in optional devices or memory. When a change is detected, the
driver is automatically updated with the new settings.
Memory
Memory is the amount of standard and optional memory installed in the printing
system. To maximize the downloading of printing system fonts, the driver must
be set to match the total printing system memory.
Setting the Memory
By default, the Memory setting matches the standard memory in the printing
system. If optional memory is installed, set the memory in the printer driver to
match the total amount of memory.
1
Install optional DIMM memory in the printing system.
User Guide
2-3

Table of Contents

Other manuals for Kyocera FS-2020D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-2020D and is the answer not in the manual?

Kyocera FS-2020D Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Memory typeDDR2
Processor modelPowerPC 440
Maximum internal memory1152 MB
Sound power level (standby)29 dB
Sound pressure level (printing)52 dB
Power supply type220/240 V, 50/60 Hz
Capacity cartridge12000 sheets
Power consumption (active)560 W
Recommended monthly print volume20000 pages
Maximum duty cycle150.000 pages per month
Number of print cartridges1
Total input capacity500 sheets
Total output capacity250 sheets
Maximum input capacity1100 sheets
Maximum number of input trays2
Multi-Purpose tray input capacity100 sheets
Maximum print size216 x 356 mm
Paper tray media typesPlain paper, Recycled paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)9.2 W
Power consumption (PowerSave)5.7 W
Energy Star Typical Electricity Consumption (TEC)2.6 kWh/week
DisplayLCD
CertificationGS, TüV, CE
Standard interfacesParallel, USB 2.0
Optional connectivityEthernet, Wireless LAN
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)382 x 394 x 285 mm
