Kyocera FS-4200DN User Manual

4-41
Operation Panel
Duplex (Setting the duplex printing)
Using the duplexer, you can automatically print on both sides of the paper.
Duplex printing is available for the following paper (media) types:
Plain
Preprinted
Bond
Recycled
Rough
Letterhead
Color
Prepunched
High Quality
Custom 1 to 8
Binding Modes
Binding refers to the manner in which printed pages of paper are joined together (by gluing, stitching, etc.) in book form.
The two possible types of binding are: Bind Long Edge, in which pages are joined together along their long edge; and Bind
Short Edge, in which they are joined together along their short edge. In selecting a binding type, you must also consider the
orientation of the printed page. You can use Bind Long Edge or Bind Short Edge with either landscape or portrait printing.
Depending on the binding type and print orientation, the duplexer provides four types of binding. These are: (1) portrait, Bind
Long Edge, (2) portrait, Bind Short Edge, (3) landscape, Bind Long Edge, and (4) landscape, Bind Short Edge. The figure
below shows these binding methods.
1 In the Print Settings menu, press U or V to select Duplex.
2 Press [OK]. The Duplex screen appears showing the list of available
duplex printing modes.
3 Press U or V to select the desired duplex printing mode.
The message display toggles through the following:
Off (default)
Note Duplex printing can be also performed from the MP tray. If the paper to be fed from the MP tray does not
match the paper size and paper type of the current paper feed source cassette, a paper jam may occur.
When Custom is specified, duplex printing can be set. For details, refer to Custom Paper Settings on page 4-36.
(1)
(3)
(2)
(4)
Portrait,
Bind Long Edge
Landscape,
Bind Long Edge
Portrait,
Bind Short Edge
Landscape,
Bind Short Edge
Duplex: a b
********************-
2 Bind Long Edge
3 Bind Short Edge
1 *Off

Kyocera FS-4200DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Printing colors	Black
Maximum duty cycle	250000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD, SDHC
Maximum internal memory	1280 MB
Sound power level (standby)	27.3 dB
Sound pressure level (printing)	54.4 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
