Kyocera FS-4200DN User Manual

4-31
Operation Panel
Custom
Oufuku Hagaki (#3)
Oficio II
216x340mm
16K
Statement
Folio
Youkei 2 (#2)
Youkei 4 (#2)
(#1): Cassette 1 for the FS-4100DN, FS-4200DN and
FS-4300DN.
(#2): Only when optional paper feeder PF-320 is installed.
(#3): Cassette 1 except for the FS-2100D and FS-2100DN.
5 Press U or V to select the desired paper size.
6 Press [OK]. The paper size for the cassette is set and the Cassette
# Set. menu screen reappears.
If you selected Custom in step 4, use the procedure below to specify
the paper length and width.
Custom PaperSize (Setting a Custom Paper Size)
In the procedure below, select the units to be used for entering the custom paper size and then enter the paper width and
length. As shown in the figure, enter the Y and X values for the paper size, using the selected units.
Note When Custom is selected, it is possible to enter the
paper size. For details, refer to Custom PaperSize (Setting a
Custom Paper Size) on page 4-31.
X Dimension
Y Dimension
Cassette (FS-2100D, FS-2100DN):
140 to 216 mm (5.5 to 8.5 inches)
Cassette (FS-4100DN, FS-4200DN, FS-4300DN):
105 to 216 mm (4.13 to 8.5 inches)
Paper Feeder PF-320:
92 to 216 mm (3.62 to 8.5 inches)
Cassette (FS-2100D, FS-2100DN):
210 to 356 mm (8.25 to 14.02 inches)
Cassette (FS-4100DN, FS-4200DN, FS-4300DN):
148 to 356 mm (5.83 to 14.02 inches)
Paper Feeder PF-320:
162 to 356 mm (6.38 to 14.02 inches)

Kyocera FS-4200DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Printing colors	Black
Maximum duty cycle	250000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD, SDHC
Maximum internal memory	1280 MB
Sound power level (standby)	27.3 dB
Sound pressure level (printing)	54.4 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
